Size Chart Cervelo Caledonia
|
48 |
51 |
54 |
56 |
58 |
61 |
| Reach | mm
|
360 |
369 |
378 |
387 |
396 |
405 |
| Stack | mm
|
505 |
530 |
555 |
580 |
605 |
630 |
| Head Tube Angle
|
70.5° |
71.5° |
72° |
72° |
72° |
72° |
| Front Center | mm
|
579.4 |
581.7 |
591.5 |
608.5 |
626 |
643 |
| Bottom Bracket Drop | mm
|
76.5 |
76.5 |
74 |
74 |
71.5 |
71.5 |
| Head Tube Length | mm
|
89.5 |
109.9 |
136 |
162.3 |
191.2 |
217.5 |
| Top Tube Length | mm
|
502 |
522 |
543 |
565 |
581 |
598 |
| Seat Tube Angle
|
74.5° |
74° |
73.5° |
73° |
73° |
73° |
| Standover Height | mm
|
701 |
741 |
773 |
796 |
823 |
847 |
| Trail | mm
|
60 |
60 |
60 |
60 |
60 |
60 |
| Wheel Size
|
700C |
700C |
700C |
700C |
700C |
700C |
| Fork Offset | mm
|
59 |
53 |
50 |
50 |
50 |
50 |
| Wheelbase | mm
|
982.2 |
984.5 |
995.2 |
1012.3 |
1030.7 |
1047.8 |
| Chainstay Length | mm
|
415 |
415 |
415 |
415 |
415 |
415 |
