Mavic - COSMIC ULTIMATE 45 DISC

$5,270.00 $6,200.00

CCU Ultimate is not just a name, it’s the word we reserve for pinnacle performance. And it’s now finally compatible with tubeless and clincher tyres and for disc brake bikes.
At just 1255g, this wheelset is the ultimate balance of lightweight, stiffness and aerodynamics.

The rim is engineered with a NACA-inspired, full-carbon profile that’s 45mm deep and 27mm wide. It’s made from a complex lay up that optimizes the stiffness to weight ratio. Its external layer takes our distinctive UD² finish.
The rim is not drilled, so it doesn't require the use of a rim tape to become airtight: a guarantee for a hassle free tubeless use.

The 20 elliptical carbon fiber spokes and high, thin carbon hub flanges offer a proven aero advantage.

The spokes are made with unidirectional carbon fibers, so they don’t stretch. The spokes run continuously from one edge of the rim to the other, through the hubs (R2R technology), creating one single spoke instead of two. This adds wheel stiffness and eliminates the need to mechanically attach the spokes to the hub.

Inside the carbon hub shells, the axles are paired with automatically adjusted sealed cartridge bearings for perfect preload. At the back, the ID360 freewheel system provides instant engagement (40 points of engagement = 9°) and low friction. The hubs are thru-axle compatible (12x100 up front and 12x142 at the back) and made for Center Lock brake rotors.

Ultralight and aero help you climb, sprint and accelerate faster

Monobloc full carbon construction
45mm NACA rim profile seamlessly laced with elliptical spokes on high thin hub flanges

Stiffest wheel system in its class with super low rolling resistance for high reactivity

Carbon spokes with high tensile resistance
Rim to rim (R2R) lacing system
Tapeless tubeless UST rim

Handmade in France

Manual molding and assembling process
Developed and manufactured in the Mavic carbon workshop in Annecy, France
Delivered with exclusive wheelbag

SPECIFICATIONS

Weight

Weight Pair : 1255 g
Weight Front : 575 g
Weight Rear : 680 g

Rims

Material: 100% carbon fiber with UD external layer
Height: 45 mm
Internal width: 19 mm
Drilling: co-molded Fore drilled inserts (front/rear 20 holes)
Braking: disc
ETRTO size: 622x19TC
Tire: UST Tubeless Ready

Spokes

Material: unidirectional carbon fiber
Shape: straight, extra-flat (front and rear)
Lacing: crossed 2 (front and rear)

Hubs

Body material: carbon and aluminium
Disc standard: Center Lock® only
Axle material: aluminum
Axle size: front 12x100 / rear 12x142 - Convertible to quick release with included adapters
Freewheel technology: Instant Drive 360
Freewheel: Shimano HG road
Bearing technology: QRM automatic setting - sealed cartridge

Intended use

Minimum tyre size: width 23mm - pressure max. 6.75Bar/97PSI
Maximum tyre size: width 62mm - pressure max. 3.8Bar/55PSI
ASTM category 1 : road only
Maximum weight supported by the wheels: must not exceed 120 kg (bike weight included)
